EM DE16 Digital input module

16-point digital input,24VDC,47×100×81mm

Model no

EM DE16

Article No

H7 288-2DE16-0AA0

Description

16-point digital input,24VDC

Dimensions WxHxD(mm)

47×100×81mm

Product parameters Wiring diagram Relevant information
Specification parameters Model no

EM DE16

Article No H7 288-2DE16-0AA0
Description 16- digital input,24VDC
Conventional norm

Dimensions WxHxD(mm)

47×100×81mm
Power Consumption 2.3W
Current Consumption(SM bus) 130mA
Current Consumption(24V DC) 4mA for each input point used
Digital input

Number of Inputs

16
Input type PNP/NPN (IEC type 1 sinking)
Rated voltage 24V DC when the current is 4mA, Rated Value
Allowable Continuous Voltage Max 30VDC
Surge voltage (Maximum) 35VDC,lasting 0.5s
Logic 1 signal (Minimum) it is 15V DC when the current is 2.5mA
Logic 0 signal (Maximum) it is 5V DC when the current is 1mA
Optical Isolation (field side and logic side) 500V DC,lasting 1.0min
Isolation group 4
Filter time 0.2、0.4、0.8、1.6、3.2、6.4 and 12.8 ms(optional, 4 inputs form one group)
Number of inputs that connect at the same time 16
55° (horizontal) All
45° (vertical) All
Cable length (Max)

Shield

500M
Unshielded 300M
